SYIL X7 Small CNC Machine

Features Overview Table Table size: 700×300 mm T-slots (Number×Size×Distance): 3×14×100mm Maximum table load: 150 kg Route X travel: 400 mm Y travel: 300 mm Z travel: 380 mm Distance between the end of the spindle and the table surface: 150-530mm Distance between spindle and column surface: 358 mm Spindle Spindle taper: BT30 Spindle speeds: 10,000 rpm Transmission mechanism: Belt Advance Cutting feed: 10,000 mm/min Rapid travel: 30,000 mm/min Automatic tool changer Tool Type: Umbrella Tool storage capacity: 12 pieces Maximum tool diameter: 63mm Maximum tool length: 200mm Maximum tool weight: 3 kg From tool to tool: 1.5 s Power Spindle motor output (Nominal/Maximum): 2.2/3.0 kW Drive motors (X, Y, Z): 0.85/1.3/1.3 kW Power Supply: AC220V/1-Phase Power: 7 kVA
